Mucking loader is also called excavating loader, integrates multiple functions including excavation, conveying, loading, running, Because of its high working efficiency, strong ability to adapt the sp
Contact Us Product CenterMucking loader is also called excavating loader, integrates multiple functions including excavation, conveying, loading, running, Because of its high working efficiency, strong ability to adapt the space, less polluting to the air inside of the tunnel, it becomes a very important mechanical equipment in tunnel construction. It can be full-face loading of gravel, leaving no dead ends, do not need to manually clean up Site, you can also digging on both sides of the roadway ditch.
1) Load sensing hydraulic priority to, stable and reliable, energy conservation and significant.
2) Durable, each gear ratio reasonable matching, reduce the power consumption.
3) Reduce the power consumption.
4) Simple structure and reliable performance.
5) Semi-enclosed assembling,easy to maintain.
|
Machine Slag Model |
ZWY-80/40L |
|
Technical productivity |
80m3/h |
|
Max excavation height |
2300mm |
|
Max excavation width |
3500mm |
|
Max excavation depth |
400mm |
|
Max digging force |
1.5T |
|
Gradeability |
300mm |
|
Fuel tank capacity |
260L |
|
Machine weight |
8000kg |
|
Walking speed |
0.63km/h |
|
Unload distance |
2000mm (can add length) |
|
Unload weight |
1400-1600mm (can add length) |
|
Dimensions (L*W*H): |
7120x1500x2200 (Working state) |
|
6150x1500x1830 (Transport status) |
