ZWY-100/45 Crawler mucking loader main feature is that the displacement of the main pump is proportional to the signal pressure output by the pilot operating handle. The main controller judges the flo
Contact Us Product CenterZWY-100/45 Crawler mucking loader main feature is that the displacement of the main pump is proportional to the signal pressure output by the pilot operating handle. The main controller judges the flow demand of the actuator and its changing trend according to the pilot pressure signal and its changing trend, and accordingly adjusts the flows of main pump,so that the flow supply of the system can dynamically satisfy the flow demand of system actuator. he system has a small loss of medium flow in the relative negative flow system, and the reliability is higher in the relative load sensitive system, and the compound action is more energy efficient. This series of machines has an efficiency of about 8% higher than other models, and the energy consumption has dropped by about 10%.
Main Parameter of|
Performance project |
unit |
parameter |
|
Technical productivity |
M3/h |
100 |
|
Max. Digging height |
mm |
2400 |
|
Max.digging width |
mm |
3600 |
|
Max.digging depth |
mm |
430 |
|
Max.digging force |
T |
1.5 |
|
Small section size |
m |
2.2x2.4 |
|
gradeability |
degree |
15 |
|
Ground clearance |
mm |
300 |
|
Grouding pressure |
mpa |
0.056 |
|
Motor power |
kw |
37or45 |
|
Fule tank capacity |
L |
280 |
|
Total weight |
kg |
8500 |
|
Walking Speed |
Km/h |
0.63 |
|
Unloading distance |
mm |
2500 |
|
Unloading height |
mm |
1350 |
|
Rated work press |
mpa |
10 |
|
Dimention |
mm |
7950x1700x2200 |
